• "Connected" display (10)
Status of the connection with the
PARKSIDE app
flashing connection attempt
continuous light connection estab-
lished
• Function selection switch (6)
NOTICE! Risk of damage! Only oper-
ate the function selector switch when
the tool has stopped.
Use the function selector switch (6)
to select the operating mode of the
device.
Unlock the function selection switch (6)
by pressing the retaining knob (5).
Turn the function selector switch (6)
so that the desired symbol clicks into
place at the arrow mark (see Selecting
the operating mode, p. 34).
Attaching and removing the
attachment tool
Notes
• Tool holder (1): SDS-Plus
• The attachment tool exhibits some radi-
al play for technical reasons. This has
no effect on the accuracy of the hole.
• Before working, clean the attachment
tool with SDS holder and grease the in-
sertion end slightly with the grease (21)
included in the scope of delivery (0.5 -
1 g).
• Ensure the dust cap (2) is not damaged
when inserting tools. The dust cap (2)
largely prevents drilling dust from enter-
ing the tool holder during operation.
NOTICE! A damaged dust cap (2)
must be replaced immediately. It is re-
commended to have this done by a ser-
vice centre.
• Directional data viewed from behind.
Attaching the attachment tool
(Fig. B)
1. Unlock the SDS-Plus tool holder (1):
Pull the locking sleeve (3) backwards.
2. Insert the attachment tool into the SDS-
Plus (1) tool holder by turning it.
3. Clamp the attachment tool: Release the
locking sleeve (3).
4. Check that the attachment tool is firmly
secure by pulling on it.
Removing the attachment tool
(Fig. B)
1. Unlock the SDS-Plus tool holder (1):
Pull the locking sleeve (3) backwards.
CAUTION! Risk of burn injury!
2.
Attachment tools – especially drills –
can become very hot. Wear protective
gloves whenever appropriate.
Remove the attachment tool.
Adjusting the auxiliary
handle
Notes
• The auxiliary handle (20) can be ro-
tated 360° on the device and can be
moved to any desired/necessary posi-
tion.
• Directional data viewed from behind.
Attaching the auxiliary handle
(Fig. C)
1. Turn the grip (28) of the auxiliary
handle (20) ⭮ . This extends the loop
(19).
2. Slide the loop (19) on the auxiliary
handle (20) behind the locking sleeve
(3). Position the loop (19) in the holder
for the auxiliary handle (4).
3. Tighten the grip (28) of the auxiliary
handle (20) ⭯ .
GB
MT
33
