FILL-RITE FR102PHU Manuel D'installation Et D'utilisation page 8

|
FR102PHU Cabinet Bottom Wiring and Plumbing Entry Points
Item Description
A Electrical Wiring Conduit
B Plumbing Inlet
View is from below, with cabinet mounted on pedestal.
FR102PHU Junction Box Access
fillrite.com
REMOTE DISPENSING CABINETS
Wiring opening in
junction box.
INSTALLATION AND OPERATION MANUAL
Back of Cabinet
Explosion proof junction
box wiring cover.
Removable Side
Access Panel
8
