Electrical Installation
WARNING
Overall dispenser installation and electrical wiring should be performed ONLY by a licensed electrician and service personnel in compliance with
local, state, and national electrical code NEC/ANSI/NFPA 70, NFPA30, NFPA 30A, and NFPA 395 as appropriate to the intended use of the dispenser.
Threaded rigid conduit, sealed fittings, and conductor seal should be used. The pump must be properly grounded. Improper installation or use of this
dispenser can result in serious bodily injury, or death!
CAUTION
All electrical appliances should operate at the rated nameplate voltage. Power should be supplied to this dispenser from a dedicated circuit
breaker appropriately sized to handle the pump being used with the dispenser. No other equipment should be powered by this circuit. Wiring
must be of sufficient size to carry the correct current for the pump. Voltage drop will vary with distance to pump and size of wire; refer to the
National Electrical Code (NEC), or local codes, for voltage drop compensation to be sure you are using the correct size wire for your application.
Model
FR102PHU
FR902DPU
FR302DPU
Refer to the section of this manual pertaining to your particular model for detailed wiring information. All wiring connections must be made inside the
explosion proof junction box built into every dispenser cabinet. Use extreme caution when wiring in this junction box to maintain the integrity of the
explosion proof design. The 300 Series pump inside the FR302DPU cabinet has a wiring junction box on the pump for the pump wiring (see diagram
page 11 and 12).
Plumbing Installation
NOTICE
Remote dispensers and tank top pumps must be installed in accordance with all local, state, and national electrical code NEC/ANSI/NFPA 70, NFPA
30, NFPA 30A, and NFPA 395.
CAUTION
Threaded pipe joints and connections should be sealed with the appropriate sealant or sealant tape to minimize the possibility of leaks.
Your Fill-Rite dispenser cabinet should be installed in a manner that does not use the plumbing to support the cabinet in any way. Safety and Emergency
equipment should be installed per local, state, and national plumbing for flammable fuels guidelines. The following plumbing diagrams are suggestion for
typical installation scenarios.
fillrite.com
REMOTE DISPENSING CABINETS
Cabinet Dispenser Electrical Rating
Voltage (V AC)
Frequency (Hz)
125
250
115/230
Current (A)
60
20
60
20
60/50
9.8/4.9/11.4/5.7
INSTALLATION AND OPERATION MANUAL
Power (HP)
1
2
3/4
5
