2610051827 GCM12SD 08-18.qxp_GCM12SD 9/19/18 2:52 PM Page 37
Right Side
7"
2"
For safety, the switch lever is designed to pre-
vent accidental starts. To operate safety switch,
slide the switch "Lock-OFF" release button with
either thumb to disengage the lock, then pull
the power switch trigger and release the switch
"Lock-OFF" release button (figure 39). When
the power switch trigger is released, the switch
"Lock-OFF" release button will engage the
power switch trigger automatically, and the
lever will no longer operate until either "Lock-
Off" release button is engaged again.
NOTE: Power switch trigger can accommodate
a padlock with a long shackle of up to 5/16" in
diameter (not provided with miter saw) to pre-
vent unauthorized use.
.800.544.2843
Preparing for Saw Operations
9.5"
SLIDE CUT
NOTCH OUT
2-5/8"
Fig. 38
Tall Auxiliary Wood Fence - 3/4" Thick
Switch Activation
www.calcert.com
15
10
20
5
25
30
0
7"
2-1/2"
26"
Saw Operations
Fig. 39
Padlock
Hole
4 Mounting Holes
Left Side
7"
2-5/8"
2"
Switch "Lock-OFF"
Release Buttons
Power Switch
sales@calcert.com
5-1/2"
Lever
37
