17T Series Installation
Installation and Adjustment of the Temperature Knob
4
Failure to do so may cause injury.
2
1
7
6
Adjust temperature limit stop! Turn on
water supplies; let the water run at both
full hot and full cold to ensure the water is
running as hot/cold as possible. Place a
thermometer in a plastic tumbler, and hold
the tumbler in the water stream. Place the
temperature knob (1) onto the splines (2),
then rotate the temperature knob until
you achieve your maximum desired
temperature from the outlet (not more
Cleaning and Care
Care should be given to the cleaning
of this product. Although its finish is
extremely durable, it can be damaged by
harsh abrasives or polish. To clean, simply
wipe gently with a damp cloth and blot dry
with a soft towel.
5
4
3
than 120° or the lower temperature
mandated by your local plumbing code).
Remove the temperature knob and replace
onto the splines (2), making sure that the
temperature knob limit stop (3) hits against
the volume handle limit stop (4) as shown.
Secure volume handle with set screw (5).
Secure the temperature knob using screw
(6) and place cap (7) on knob.
Warning: Scrubbing Bubbles
Cleaner and Lysol
Cleaner must not be used on the clear knob
handles and levers. Use of these cleaners
can result in cracked or severely damaged
handles. If overspray gets onto the handles,
immediately wipe them dry with a soft
cotton cloth
14
4
3
1
Bathroom
®
Basin Tub and Tile
®
