EC5000 50 W – 24 V DC/48 V DC
Gear Conveyor speed
ratio 50mm roller [m/s]
Max.
9:1 2,01
13:1 1,39
18:1 1,00
21:1 0,86
30:1 0,60
42:1 0,43
49:1 0,37
78:1 0,23
108:1 0,17
All data applies for an ambient temperature of 20 °C (68 °F).
* Before the run-in, the values can vary by up to ±20%. After the run-in phase, the values for 95% of all RollerDrives
used vary only in the range of ±10%.
32 of 116
Rated
torque
Min.
[Nm] *
0,09 0.63
0,06 0.91
0,04 1.27
0,04 1.48
0,03 2.13
0,02 2.96
0,02 3.45
0,01 5.07
0,01 7.07
Acceleration Continuous
torque blocking
torque
[Nm] * [Nm] *
1.58 1.58
2.29 2.29
3.17 3.17
3.70 3.70
5.34 5.34
7.40 7.40
8.63 8.63
13.00 13.00
13.00 13.00
Translation of the original operating manual
Breakaway
torque
[Nm] *
2.54
3.66
5.07
5.92
8.54
11.83
13.00
13.00
13.00
