Product information
3.8

Performance data

EC5000 20 W – 24 V DC/48 V DC
Gear Conveyor speed
ratio 50mm roller [m/s]
Max.
9:1 2,01
13:1 1,39
18:1 1,00
21:1 0,86
30:1 0,60
42:1 0,43
49:1 0,37
78:1 0,23
108:1 0,17
All data applies for an ambient temperature of 20 °C (68 °F).
* Before the run-in, the values can vary by up to ±20%. After the run-in phase, the values for 95% of all RollerDrives
used vary only in the range of ±10%.
Rated torque
Torque that the RollerDrive can deliver at an ambient temperature of 20 °C (68 °F) and at the rated speed during
continuous operation.
Acceleration torque
Torque available to the RollerDrive during operation to counteract a load.
Acceleration torque = rated torque x 2.5.
The acceleration torque cannot be greater than 13 Nm.
Continuous blocking torque (Zero Motion Hold)
Continuous blocking torque = Acceleration torque.
30 of 116
Rated
torque
Min.
[Nm] *
0,09 0,25
0,06 0,36
0,04 0,50
0,04 0,59
0,03 0,85
0,02 1,18
0,02 1,37
0,01 2,02
0,01 2,82
Acceleration Continuous
torque blocking
torque
[Nm] * [Nm] *
0,63 0,63
0,91 0,91
1,26 1,26
1,47 1,47
2,13 2,13
2,95 2,95
3,44 3,44
5,43 5,43
7,57 7,57
Translation of the original operating manual
Breakaway
torque
[Nm] *
1,01
1,46
2,02
2,36
3,40
4,71
5,50
8,68
12,12
