Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and
maintenance information.
Para instalación fácil de su llave
Delta usted necesitará:
• LEER TODAS las instrucciones
completamente antes de empezar.
• LEER TODOS los avisos, cuidados,
e información de mantenimiento.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de
débuter.
• LIRE TOUS les avertissements ainsi que
toutes les instructions de nettoyage et
d'entretien.
R4707 DECK MOUNT ROMAN TUB
WITH HAND HELD SHOWER DIVERTER
ROUGH-IN KIT
JUEGO DE PIEZAS PARA LA TUBERÍA
INTERNA R4707 PARA LA INSTALACIÓN
EN BORDES DE BAÑERAS ROMANA CON
DESVIADOR MANUAL PARA REGADERAS
DE MANO
KIT DE PLOMBERIE BRUTE R4707 DE
ROBINET DE PLAGE DE BAIN ROMAIN
AVEC DÉRIVATION POUR DOUCHE À MAIN
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
Finished Deck
(Standard) Installation
Use these instructions on a fin-
ished deck installation up to 2 1/2"
(63.5 mm) thick.
Instalación (Estándar) para
Bordes Acabados
Use estas instrucciones para
la instalación en bordes hasta
2 1/2" (63.5 mm) de grosor.
Installation standard dans une
plage finie
Suivez ces instructions pour installer
un robinet dans une plage finie
épaisse d'au plus 2 1/2 po (63.5 mm).
Rough Deck (Thick Tile) Installation
Use these instructions on a rough
deck (thick tile) installation up to
2 1/2" (63.5 mm) thick (excluding
plywood underlayment).
Instalación de las Tuberías Internas
en los Bordes (Losas Gruesas)
Use estas instrucciones en instalacio-
nes en los bordes (de losas gruesas)
hasta de 2 1/2" (63.5 mm) de grosor
(incluyendo el contrapiso de madera
polywood)
Installation dans une plage en
carreaux
Suivez ces instructions pour installer
un robinet dans une plage en
carreaux épaisse d'au plus 2 1/2 po
(63.5 mm) (épaisseur du panneau de
sous-finition en contreplaqué exclue).
US. Pat. 3,645,493, 3,786,995, 4,523,604, 4,562,960, 4,593,430, 4,218,785, 4,577,653, 4,765,365
1
7/11/07 Rev. B
