Control Drawing
Hazardous (Classified) Location
Class I, Division 1, Groups A,B,C,D
Class I, Zone 1, Groups IIA, IIB, IIC
Display Unit
7)
SARTORIUS
Weighing Unit
Series
PMA35001-X..
!
Data Interface Board
11)
T-Connector
13)
Any NRTL approved equipment with
Entity Concept parameters
E.g. SARTORIUS Indicator
CIXS3-.
2012-10-18
Dr. D. Klausgrete
36
Mode d'emploi PMA 35001-X
5)
6)
3)
8)
5)
9)
10)
5)
10) or 12)
5)
9)
3)
14)
Hazardous (Classified) Location
Class I,II,III, Division 1,
Groups A,B,C,D,E,F,G
Canada: Group A is excluded!
SARTORIUS
Power Supply Type
4)
YPS02-XUR
YPS02-XKR
Hazardous (Classified) Location
Class I,II,III, Division 2,
Groups A,B,C,D,E,F,G
Class I, Zone 1, Groups IIA, IIB
Class II, Zone 21
SARTORIUS
4)
Rechargeable
Battery Pack
YRB02-X
Non-Hazardous Location
SARTORIUS
4)
Power Supply Type
YPS02-ZKR
Any NRTL approved
equipment with Entity
Concept parameters
E.g. SARTORIUS
13)
Interface Converter Type
YDI05-Z
or SARTORIUS
Energy Limiting Unit Type
YELU01-ZM..
: Alternative connection
Title
Control Drawing
Drawing
36953-761-07
number
2)
Power
18)
3)
18)
17)
2)
Power
16)
3)
2)
Data
3)
15)
19)
1
3
Page
of
00
Revision
