User Instruction - Beeper RW075LDV Manuel D'installation & D'utilisation

USER INSTRUCTION

SAFETY PRECAUTIONS
• The reversing camera cannot in any circumstances be a substitute for the vigilance and responsibility of the driver.
• The reversing aid is for information only, the security of the vehicle and the people close to it is the responsibility of the driver. The driver must check if there are any obstacles or people near the
vehicle. We can not be held responsible in the case of a collision.
• It is the driver's responsibility to judge the distance of obstacles and they must adopt careful and cautious behaviour while driving so as not to endanger
persons or cause damage.
• The positioning of the screen should not interfere with the driver's vision, the recommended position is near the rear-view mirror but without obscuring it in
any way.
• If necessary, the screen must be cleaned using a slightly damp, soft cloth, do not press on the LCD screen as this
may cause damage.
• If necessary, the camera lens must be cleaned using a soft damp cloth.
ACTIVATING AND DEACTIVATING THE SYSTEM
The system is activated automatically when the driver moves into reverse gear. It turns off automatically when the driver switches to another gear or moves into
neutral.
GUIDELINES FOR JUDGING DISTANCE
Depending on the configuration chosen during the installation of the product, guidelines for judging distances may appear on the screen (Fig. 1). These
guidelines are to help the driver to judge the distance between their vehicle and the obstacles they can see on the screen. They can be disabled when the product
is installed. If you want to change whether the guidelines are activated or deactivated subsequent to the initial installation, please contact your installer.
ADJUSTING THE MONITOR BRIGHTNESS
The bottom button on the screen (button # 2 -. Fig. 2) is for users to adjust the level of brightness. Press this button to enter the relevant menu, the "brightness"
icon will appear on the screen. By pressing the button users can increase or decrease the brightness level to suit their preference.
REVERSING THE IMAGE
The top button (No. 1 -. Fig. 2) allows the image to be reversed from top to bottom. This feature is useful for the installation of the product and should not be
selected when using the system to judge the distance between the vehicle and obstacles or persons in a real-world scenario.
29
Fig.1
1
2
Fig.2
