Beeper RW075LDV Manuel D'installation & D'utilisation page 21

GENERAL DIAGRAMM
NOTA BENE
You can connect cable directly on cable
C
if length of your car does not need 400 cm.
A
Cable can be connected between cables
C
& (power cable on the back of the car)
B
D
Cable can be connected between cables
C
& (power cable on the front of the car)
A
B
A1 B1
A
B
EXTENSION
(Ref : RX-W75-FS1)
MONITOR 3,5''
(Ref : RX-W75-M1)
12V Reverse light
400 cm B2 C2
C
21
Ground
C3
POWER CABLE
(Ref : RX-W75-FS2)
"Canon" connector female
"Canon" connector male
"Box" connector female
D1
D
CAMERA
(Ref : RX-W75-C1)
