Installation instructions, only for experts

6.5. Seat time (optional for seat sensor)

DIP-Bank 2
Function selection switch 1 and 2
By selecting the seat time, the time for the
optional seat sensor available can be set.
After the set operating time has elapsed,
the infrared heater/infrared plate switches
off automatically.
The operating time can be adjusted us-
ing the function selection switch. For the
required position of the function selection
switch, see the following table.
Function
selection switch
5 min.
10 min.
15 min.
20 min.
Note: Seat operating mode (see 6.1. Operating mode on page 19) must be
activated to be able to use the function.
Example: Seat-time 5 min.
EIN
AUS
1 2
OFF OFF
ON OFF
OFF ON
ON ON
Gesamtlaufzeit (siehe 6.3 Laufzeit)
Auto
Sitzplatzlaufzeit
5 min
Fig. 13:Seat-time
p. 23/32
ON
