Installation instructions, only for experts

4. Installation

4.1. Installing the power supply unit

The power supply unit is installed on the cabin roof (Fig. 1), on the cabin wall or
in another suitable location in accordance with the ambient conditions. The power
is supplied with a mains connection cable and safety plug.
ATTENTION!
Damage to the unit
● Install the power supply unit in a dry place. Maintain a maximum ambient
temperature of 40 °C and a maximum humidity of 95%.
● A free circulation of air must be ensured to cool the power supply unit.
The power supply unit must not be covered by any objects or materials.
Fig. 1
1. Screw the Infrabox power supply unit housing to the cabin ceiling or the cabin
wall with the four wooden screws provided (16 mm long).
Installing the power supply unit
p. 11/32
