12. LiXX charge program without balancer
Charging LiXX batteries without a balancer connection:
ATTENTION: if the balancer lead is not connected, the individual cells in the battery will not be balanced!
LiPo CHARGE:
Press the 'Batt. Type / Stop' button to move to the PROGRAM SELECT - LiPo BATT menu. Now press 'Start - Enter' for the
3 sec.
'LiPo CHARGE' menu.
The default pre-set charge current and cell count are displayed on the screen. If you wish to change these settings, press 'Start
- Enter' again: the charge current starts to flash, and can now be changed using the DEC or INC button. Pressing the 'Start -
Enter' button again takes you to the cell count, which can be adjusted in the same manner. A further option at this point is to
select AUTO: the cell count of the battery connected to the charger is detected automatically, and the charge process starts
immediately when you press the 'Start - Enter' button.
When the settings are correct, hold the 'Start - Enter' button pressed in for three seconds; the charger then initiates the automa-
Battery
Number
voltage
of cell Charging
tic cell detect process BATTERY CHECK (please refer to Chapter 11 for details of programming the CHK time) and displays the
charged
time
capacity
values on the screen. If everything is correct, press the 'Start - Enter' button to start the charge process. If you need to correct
Charging current
the values again, you can interrupt the procedure with 'Stop'.
To interrupt the charge process before it terminates automatically, press the 'Stop' button.
WARNING: it is absolutely essential to enter the correct charge current and cell count at this point, otherwise the
battery may be damaged or - worse - ignite or even explode!
