Operating Jvc's Audio/Video Components - JVC RX-DV5SL Manuel D'instructions

Operating JVC's Audio/Video Components

You can operate JVC's audio and video components with this unit's remote control, since control signals for JVC's components are preset in the
remote control.
Operating Audio Components
To operate JVC's audio components using this remote control
• Aim the remote control directly at the remote sensor on the unit.
• To operate a source with the remote control, the source must be
selected using the source selecting buttons on the remote control.
• Refer also to the manuals supplied with your components.
7
Sound control section (Amplifier)
After pressing CONTROL repeatedly to show "SOUND" on the
operation mode display, you can perform the following operations:
TV/DBS CH +
CONTROL EFFECT CENTER
1 2 3
ANALOG
TEST REAR·L
/DIGITAL
4 5 6
INPUT
AUDIO SURR ON/OFF REAR·R
7 8 9
– +
SUBTITLE SURR MODE SUBWOOFER
10/0 +10 VFP
100+ TV RETURN
SURR ON/OFF : Turns on or off the Surround modes—
Dolby Digital, DTS Digital Surround, and
Dolby Pro Logic II.
SURR MODE : Selects the Surround modes.
TEST : Turns on or off the test tone output.
CENTER + or – : Adjusts the center speaker channel output
level.
REAR•L + or – : Adjusts the left rear speaker channel
output level.
REAR•R + or – : Adjusts the right rear speaker channel
output level.
SUBWOOFER + or – : Adjusts subwoofer channel output level.
EFFECT : Selects the effect level.
Note:
• After adjusting sounds, press the source selecting button to operate
your target source by using number buttons; otherwise, number
buttons cannot be used for operating your target source.
61
7
CD recorder
After pressing CDR, you can perform the following operations on a CD
player and a CD recorder:
TV TAPE CDR FM/AM
DBS VCR DVD
9
TV/VIDEO REW/ ( TUNING/GROUP /FF
REPEAT SLEEP FM MODE STROBE
– TV/DBS CH +
EFFECT CENTER
CONTROL
1 2 3
ANALOG
TEST REAR·L
/DIGITAL
4 5 6
INPUT
SURR ON/OFF REAR·R
AUDIO
7 8 9
– +
SUBTITLE SURR MODE SUBWOOFER
10/0 +10 VFP
100 TV RETURN
3
: Starts playing.
4
: Returns to the beginning of the current (or previous)
track.
¢
: Skips to the beginning of the next track.
7
: Stops playing.
8 : Pauses playing. To release it, press 3.
1 – 10, +10 : Selects a track number directly.
For track number 5, press 5.
For track number 15, press +10, then 5.
For track number 20, press +10, then 10.
For track number 30, press +10, +10, then 10.
Note:
• When you start recording on the CD recorder, use the buttons on
the CD recorder itself or on the remote control supplied with it.
7
Tuner
You can always perform the following operations:
TV TAPE CDR FM/AM
DBS VCR DVD
( 9
TV/VIDEO REW/ TUNING/GROUP /FF
REPEAT SLEEP FM MODE STROBE
– TV/DBS CH +
CENTER
CONTROL EFFECT
1 2 3
ANALOG
TEST REAR·L
/DIGITAL
4 5 6
INPUT
SURR ON/OFF REAR·R
AUDIO
7 8 9
– +
SURR MODE SUBWOOFER
SUBTITLE
10/0 +10
VFP
FM/AM : Tunes into the last selected FM or AM station.
• Each time you press the button, the band changes between FM and
AM alternately.
After pressing FM/AM, you can perform the following operations on
a tuner:
1 – 10, +10 : Selects a preset channel number directly.
For channel number 5, press 5.
For channel number 15, press +10, then 5.
For channel number 20, press +10, then 10.
TUNING 9 or ( : Tunes into stations.
FM MODE : Changes the FM reception mode.
