7. Pump groups DN40 / DN50 / DN65
7.2 Pump groups MK-FL DN 40,50 and 65
9
6
7
10
Width ca. 495 mm
Pump groups FL-UK (mixed heating circuit) from DN 40 to DN 65 for the distributor set up
The groups are fully pre-assembled / tested and can be connected to the distributors using the supplied Victaulic couplings. Various adapters
are available for other types of connections.
Max. permissible pressure rating:
Max. permissible temperature:
Effiziente Energietechnik
8
1
2
3
4
1
2
3
4
5
5
6
7
8
9
10
PN 10
110 °C
KFE-cock
Thermometers (display 0-120 °C)
Barrier
Dirt trap
Victaulic clamp
Barrier with return valve
Pump
Insulation
Additional 1/2" connection (2xVL; 2xRL)
Mixer
46
