10. Technical data
Protector mini rinsefilter
Nominal connection width
Flow rate at ∆p = 0,2 bar
Admission width
Nominal pressure (PN)
Operating pressure, min./max.
Water temperature, min./max.
Ambient temperature, min./max.
Length A
Length B
Total length C
Height D
Total length E
Height F
Art.Nr.
Typ H/R ½" H/R ¾"
DN 15
m³/h 1,6
µm
bar 25
bar 1,5 during the flushing / 25
°C 5 / 70
°C
G ½"
G ¾"
mm 80
mm 160
mm 133
mm 190
810506 810507
C/R ½"
20 15
2,8 1,6
100
1,5 during the flushing / 16
5 / 40
G ¾" G ½"
G 1" G ¾"
90 80
160 164
160 133
190 194
810523
C/R ¾" C/R 1"
20 25
2,8 3,5
16
5 / 30
G ¾" G 1"
G 1" G "
5 /
4
90 100
164 164
160 184
194 194
810524 810531
