10.2 Detailed Measurement Interface

Click "Measurement" to carry out the measurement operation.
After the measurement operation is completed, if you want to display the menu, click the right mouse button in the image
area and move the mouse to the upper left corner of the screen.
10.2.1

Assist Tool

a)

Color Setting

1. Click "Color setting"
2. Setting dialog box appears.
• In the "Line" field user can set width and color of the line.
• In the "Text" field user can set the font size and color of the label.
b)

Edge Detection

1. Click "Edge Detection"
2. When selected, the icon turns blue
3. When measuring an image, the software will automatically find the edge of the object to be measured.
10.2.2

Measurement Tool

Icon
Arbitrary line
Horizontal line
Vertical line
Rectangle
Parallel lines
Perpendicular
Angle
Polygon
icon.
icon.
.
Function Icon
Arc
Circle
Concentric circles
Double circle
Line circle
Perpendicular circle
Text
Page 24
