Open Image

1. Click on "Open" icon.
2. The dialog box opens to select the desired image.
3. Select the image you want to open. The image is opened.
• Click "Scaling"
• Click "Full Screen"
• Click "1:1" . The image interface displays part of the picture. Press and hold the left mouse button to move the picture
position.
• Click "Browse"
• Click "Rotate" . User can change the image rotation clockwise or counterclockwise.
• Click "Delete" to delete current image.
• Click "Return" to close the current image interface.
. User can zoom in and out in the image.
. The image interface displays the whole image.
to browse the previous and next images.
