d)

Delete Measurement Data

1. In the measurement data list, select the data you want to delete.
2. Right-click with the mouse button: user will be prompted to delete a group of data or delete all data.
3. Select according to your needs.
e)

Select Measurement Data

1. Click the data in the measurement data list with the left mouse button.
2. The selected graph data is displayed in shades of gray.
• The color of the selected graph in the image display area becomes the reverse of the set color.
f)

Select Graph

1. Double-click the data in the measurement data list with the left mouse button.
2. Selected graph data will pop up a dialog box.
3. User can modify the color and line width of the line, and lock the selected graph.
• The locked graph can no longer be operated.
Page 27
