Operating Instructions - Kapro Prolaser 3D All-Lines 883G Manuel D'utilisation

Working in Automatic mode (self-leveling):
In automatic mode the laser level will level itself in the range
of ± 2.5° and will project 1 horizontal 360° or/and 2 vertical
360° green beams.
1. Remove the laser from the case and place it on a solid, flat
vibration free surface or on a tripod.
2. Push the locking switch #1 to the ON position. The laser
level will project a 360° horizontal beam. The beam
indicator (b) will turn on.
3. Press the beam selector button (a) - it will turn on a 360°
vertical side beam, in addition to the horizontal beam.
4. Additional click on the beam selector button will turn on a
360° vertical front beam, in addition to the other beams.
5. Additional click beam selector button (a) will switch
off the 2 verticals beams.
6. If the initial level of the laser is beyond ± 2.5°and the
automatic mode is activated the laser beams will flash. In
this case reposition the laser on a more level surface.
7. Before moving the laser level push back the locking switch
#1 to the OFF position this will lock the pendulum, and
protect your laser.
10

OPERATING INSTRUCTIONS
