1.1.2 dISplay

38
39
40
41
42

1.1.3 frOnt-SIde

46

1.1.4 BaCkSIde

60
48
49
58b

1.2 deSIgnatIOnS

1.2.1

SIgnal ChannelS

1. ....... Signal Input Select
2. ....... Gain Dial
3. ....... 3-Band Equalizer
4. ....... LEDs
5. ....... Filter
6. ....... Cue Button
7. ....... Linefader
8. ....... Crossfader Assign Switch
9. ....... Crossfader
10. ....... Crossfader Curve Dial
11. ....... Crossfader Start Switch
12. ....... Linefader Curve Dial
13. ....... Fader-Start Switch
14. ....... EQ Curve Switch
1.2.2

MIC Channel

15. ....... Mic 1/AUX Level
16. ....... Level Control LED for DJ Mic 1/AUX
17. ....... Mic 2 Level
18. ....... Level Control LED for DJ Mic
19. ....... 2-Band Equalizer for DJ Mic
20. ....... Mic Switch
1.2.3

headphOneS SeCtIOn

21. ....... Mono/Stereo Split Select Switch
22. ....... Cue EQ (Headphones Output Equalizer)
23. ....... Cue Mix (Cue/Master Signal Ratio)
24 ....... Cue Level (Volume Control Headpho-
nes Output)
1.2.4

MaSter SeCtIOn

25. ....... Master Volume, adjusts Master Volume
26. ....... LED for Master Signal
27. ....... Mono/Stereo Switch for Booth Output
28. ....... Balance Dial for Master Signal
29. ....... Booth Volume
52 55 57 55
58a 50
1.2.5

fx SeCtIOn

30. ....... BeatFX Encoder
31. ....... FX Channel Select Switch
32. ....... Time Encoder
33. ....... Time Bar Buttons
34. ....... Tap Button
35. ....... Level/Depth Dial
36. ....... Effect ON/OFF Switch
37. ....... Display
1.2.6 dISplay
38. ....... Effect Display
39. ....... FX Channel Display
40. ....... Effect Bar Resolution
41. ....... Effect BPM Indicator
42. ....... CUE BPM Indicator
1.2.7

COnneCtIOnS

43. ....... AUX
44. ....... MIC 1
45. ....... Headphones Output 1
46. ....... Headphones Output 2
47. ....... MIC 2
48. ....... Power Connection
49. ....... Master Out RCA
50. ....... Master Out Balanced
51. ....... Booth Out
52. ....... Record Out
53. ....... Send
54. ....... Return
55. ....... Channel Inputs
56. ....... GND
57. ....... Fader-Start Connection
58a. ..... USB A
58b. ..... USB B
59. ....... Kensington
60. ....... ON/OFF Switch
