Toparc RC-HD2 Mode D'emploi page 35

5
6.3
• Setting the Arc Force
It is recommended to position the Force Arc in the middle position (0) to start welding and adjust it according to welding results and preferences.
Note: the adjustment range of the arcforce is specific to the type of electrode selected.
JOB STORAGE AND RECALL
The current settings are automatically saved and will load next time the machine is used.
In addition to the current settings, it is possible to save and recall so-called «JOB» configurations.
There are 100 JOBS per welding process, the memorisation includes:
- The main parameter,
- The secondary parameter,
- Subprocesses and button modes.
JOB MODE
This mode allows you to create, save, recall and delete JOBs.
QUICK LOAD – Recall of the JOBs using the trigger when not welding.
The Quick Load is a JOB recall mode (20 max) excluding welding and possible only in MIG-MAG and TIG processes.
From a Quickload list of previously created JOBs, JOBs are recalled by pulling the trigger briefly. All trigger modes (2T/4T) and welding modes (SPOT/
STD/PLS) are supported.
PRODUCT SETTINGS
INFORMATION
This menu provides access to version numbers of the boards and software.
PROCESS
This menu allows you to choose the welding process: MIG-MAG
RC-HD2
150-290
200-385
(GMAW) , TIG (GTAW)
200-260
220-340
or MMA (SMAW)
EN
110-170
-
35
