GB-NL-F-14
Cooling System Capacity: 6.8 litres (12 Imp. pints)
Fuel Tank Capacity:
Hydraulic Tank Capacity: 52 litres (11.4 Imp. galls)
DIMENSIONS (Fig.2)
Width of cut:
Overall width:
(transport)(A)
Overall height:(B)
Overall length:(C)
Uncut turning circle:
Ground Clearance:
Sport 200
Magna 250
Wheel base:(D)
Wheel track - front:(E)
Wheel track - rear:(F)
Overall weight of machine:
with Magna 250 6-knife fixed head units 1980kg
(4363lb)
NOISE EMISSION
Conforms to the specification of Directive
EEC 79/113, 84/538, 87/252, 88/180, 88/181
Sound Power Level:
Sound Pressure Level:
VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Hand / Arm acceleration level : 1.45 m/s
Whole body acceleration level
X axis
Y axis
Z axis
RECOMMENDED LUBRICANTS
Engine oil:
Should be to MIL-L-2104C or to A.P.I.
Classification CC/CD/CE grades and
as given in the table below:
Temperature
ABOVE 25°C (77°F)
0°C to 25°C (32°F to 77°F) SAE 20 or SAE 10W-30
BELOW 0°C (32°F)
Hydraulic Oil:
To ISO.VG.46. Shell Tellus 46
or equivalent.
Grease:
Shell Darina R2 or equivalent.
GB
(14.4 US pints)
60 litres (13.2 Imp. galls)
(13.7 US galls)
(15.8 US galls)
3.50 meters (138in)
2.00 metres (78.8in) min.
1.45 metres (57in)
3.10 metres (123in)
1.30 metres (51in)
198mm (7 3/4in)
161mm (6 5/16in)
1.65 metres (65in)
1.50 metres (59in)
1.22 metres (48in)
104 dB(A) LWA (Bystander)
89.4dB(A) LpA (Operator
Ear Level)
2
2
: 0.27 m/s
2
: 0.59 m/s
2
: 0.19 m/s
Oil Viscosity
SAE 30 or SAE 10W-30
SAE 10W or SAE 10W-30
