4. Remove one of the knurled knobs from the filter holder
and slide it into the slot placed in the back side of the
microscope. (Fig. 22)
5. Once inserted, reinstall the knurled knob.
• IM-3F
6. Screw the terminal with the etched G on top of the filter
lever. Repeat the same steps for the right side, mount-
ing the B filterset. (Fig. 23)
• IM-3FL4
7. Screw the filter lever on the left side of the microscope.
(Fig. 24)
8. In order to prevent possible damages from UV radia-
tion, mount the orange protection screen as shown.
(Fig. 25)
Page 23
F ig. 22 F ig. 22
F ig. 23 F ig. 23
F ig. 24 F ig. 24
F ig. 25 F ig. 25
