5 Product information

5.1 Type key

Example:
SC Smart Controller for fixed speed pumps
SCe Smart Controller for electronic pumps
Booster Pressure boosting application
4x Number of pumps
3.0 Maximum nominal power P
DOL Direct online (direct start)
SD Star-delta starting
FC With frequency converter
5.2

Technical data (standard versions)

Mains supply voltage [V]:
Frequency [Hz]:
Control voltage [V]:
Max. current consumption [A]:
Protection class:
Max. fuse protection on mains side [A]:
Ambient temperature [°C]:
Electrical safety:

5.3 Scope of delivery

• Switchgear SC-Booster
• Wiring diagram
• Installation and operating instructions SC-Booster
• Installation and operating instructions frequency
converter (only for the SC-FC version)
• Test report acc. to EN 60204-1

5.4 Accessories

Accessories must be ordered separately:
Option
BACnet MSTP
Modbus RTU
LON
Installation and starting instructions Smart Control
[kW]
2
3~400/380 V (L1, L2, L3, PE)
50/60 Hz
24 V DC; 230 V AC
See rating plate
IP 54
See wiring diagram
0 to +40 °C
Degree of contamination II
Description
Connection to BACnet MSTP (RS485)
Connection to ModBus RTU (RS485)
Connection to LON
English
