INSTALLING IS200
The tamper switch plunger protrudes through the back of the unit, so that if the siren is pulled off
from the wall, the alarm will be activated. Ensure it is fully depressed when the siren is mounted.
If there is a gap, pack with a suitable spacing material.
Step 1. Find the location where IS200 is to be mounted.
Step 2. Using the large screws and wall plugs provided, mount on wall through the 4 x mounting
holes.
Step 3. Fix the siren cover with the securing screw.
Step 4. Enable tamper switch by selecting the Device +/- menu, then, Program Siren menu on the
Control Unit.
Step 5. Check if the installation is successful by testing from the Control Unit by arming and
disarming function.
Successful arming/disarming is indicated by the table provided in Audio Status Indication.
Note:
If 5 short-beeps are noticed while arming, it means the tamper is not correctly set. Check to
ensure that tamper is properly set and then test from Control Unit again.
Step 6. The installation is now completed.
CHANGE THE BATTERY
Step 1: Put the Control Panel into Device +/- menu and select the Program Siren sub menu; use
key finding the Siren Tamp. Off and than press OK key. The IS200 will sound a beep to
indicate the tamper is closed.
Step 2: Release the screws at the bottom of IS200 and pull the outer case out carefully.
Step 3: The battery compartment is a large box in the IS200 with a lid secured with 4 screws.
Step 4: Remove the four screws and take off the compartment lid.
Step 5: Remove the old batteries; and press the tamper once for discharging.
Step 6: Insert the new D cell alkaline batteries provided into the battery compartment, carefully to put
the batteries in the right way around.
Step 7: The IS200 will give beeps when the last battery is inserted.
Step 8: Replace the battery compartment lid with the four screws taking care not to over tighten.
Step 9: Put the Control Panel into the Program Siren menu again; use
On and than press OK key. The IS200 will sound a beep to indicate the tamper is opened.
4/16
key finding the Siren Tamp.
