1.6.3 Burners assembly
The boiler door details is shown in fig-
ure 3/a for burner mounting.
The burners must be regulated such
that the CO
value is that indicated in
2
point 1.3, with a tolerance of ± 5%.
30
1.7
WATER HEAD LOSSES
220
200
180
160
140
120
100
80
60
40
20
0
Fig. 3/a
500
1000
1500
NOTE: Water head losses obtained with ∆t 10°C.
2000
2500
3000
Water flow (l/h)
Portata acqua (l/h)
Fig. 4
