Les langues disponibles
Les langues disponibles
It has "Chinese", "Traditional Chinese" and "English" language modes.
Figure 8.5
Chapter 9
hElP
On default menu screen, select "Help",
then press "" ok key to enter into
help info screen. In the info screen,
you can browse the "FAQ", "How to",
"ECG info" and software version
information. As shown in 9.1.
Chapter 10
tEChniCal sPECiFiCations
10.1 ECG measurement
1. Amplification channels: 3.
2. Signal input: 3 embedded metal electrodes or external lead wire cable
(with 3/4 lead wires).
3. Lead selections and measuring methods: Quick measurement
by embedded electrodes; measurement by external electrodes with 3 lead
wires (single channel for Lead I, II, or III) or 4 lead wires (3 simultaneous
channels for Lead I, II and III)
4. ECG bandwidth: 0.05Hz~40Hz (Enhanced mode), 0.5Hz~40Hz
(Normal mode).
5. Internal noise level: ≤30μVp-p
6. Heart Rate measuring range: 30bpm~240bpm
7. Heart Rate measuring accuracy: ±2bpm or ±2%, whichever is greater
8. Display scale: 5.0mm/mV±10%
9. Common-mode rejection ratio (CMRR): ≥60dB
ENGLISH
Figure 8.6
Figure 8.7
Figure 9.1
60
