CONTENTS
Important Owner Information ..............................................2
Introduction ...........................................................................2
Important Safety Information...............................................3
Model Description.................................................................4
Model Designation................................................................4
Specifications........................................................................5
Plug Configurations .............................................................5
Electrical Rating Chart .........................................................6
Dimensions ..........................................................................7
Installation .............................................................................8
General ................................................................................8

IMPORTANT OWNER INFORMATION

Record the model number, serial number, voltage, and
purchase date of the unit in the spaces below (specification
label located on the back of the unit). Please have this
information available when calling Hatco for service assistance.
model No. ____________________________________
Serial No. ____________________________________
Voltage ______________________________________
Date of Purchase ______________________________
Register your unit!
Completing online warranty registration will prevent delay in
obtaining warranty coverage. access the Hatco website at
www.hatcocorp.com, select the Parts & Service pull-down
menu, and click on "Warranty Registration".

INTRODUCTION

Hatco Toast King Electric Conveyor Toasters are specially
designed to speed the toasting operation. Products pass
through a heating chamber for rapid and thorough toasting.
Dryness, moisture, sugar content, and thickness of bread
product affect the ability to achieve the perfect toasted product.
Conveyor speed, not temperature, determines the toasting
color.
Hatco toasters are quality built to meet the demands of
foodservice operations and provide years of trouble-free
performance. The metal-sheathed tubular heating elements are
guaranteed against breakage and burnout for two years. (If
failure of one element should occur, your Hatco toaster will
continue to operate - the production may be slightly lower.)
Hatco Electric Conveyor Toasters are products of extensive
research and field testing. The materials used were selected
for maximum durability, attractive appearance, and optimum
performance. Every unit is inspected and tested thoroughly prior
to shipment.
Operation ...............................................................................9
General ................................................................................9
Thermostat adjustment ........................................................9
Maintenance ........................................................................10
General ..............................................................................10
Daily Cleaning....................................................................10
Cleaning the Toasting Baskets ..........................................10
Troubleshooting Guide.......................................................11
Options and Accessories...................................................12
Limited Warranty.................................................................13
Authorized Parts Distributors............................Back Cover
Business
Hours: 7:00 to 5:00
am
(Summer Hours: June to September-
7:00 to 5:00
am
7:00 to 4:00
am
Telephone: 800-558-0607; 414-671-6350
e-mail: partsandservice@hatcocorp.com
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 800-558-0607.
additional information can be found by visiting our web site at
www.hatcocorp.com.
This manual provides the installation, safety, and operating
instructions for Hatco Electric Conveyor Toasters. Hatco
recommends all installation, operating, and safety instructions
appearing in this manual be read prior to installation or
operation of a unit.
Safety information that appears in this manual is identified by
the following signal word panels:
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to
personal injury.
2
English
Central Standard Time (CST)
Pm
CST monday-Thursday
Pm
CST Friday)
Pm
WARNING
CAUTION
NOTICE
Form No. TRTKm-0816
