BECOMING FAMILIAR WITH THE PRODUCT

4.1 Description

1
2
3
4
5
6
1 Air ducting (*)
2 Door glass
3 Door opening handle
4 Fire box grate
5 Ash drawer
6 Combustion air regulation
7 Cold handle
8 Combustion air inlet
9 Room fan (*)
004778840 - 21/07/2021
7
10
11
(*) For models V13 - V13 EPLUS
(**) Only model V13 EPLUS.
ITALIANO ENGLISH
11
10
2
Door automation (**)
Flue gas outlet
FRANÇAIS
9
8
Fig. 2
