EBM Installation

A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and
will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and
firmly.
To install the optional EBM(s):
1.
2.
3.
4.
ON
OFF
Battery Circuit Breaker
Battery Circuit
Breakers
®
EATON Powerware
Verify that all battery circuit breakers are in the OFF (O) position
(see Figure 16).
Plug the EBM cable into the UPS battery connector.
If additional EBMs are to be installed, plug the EBM cable of the
second cabinet into the battery connector on the first EBM. Repeat
for each additional EBM. Up to four EBMs may be connected to the
UPS.
Continue to the following section, "PDM Installation" or "Power
Connections and Startup" on page 21.
Figure 16. Typical EBM Installation
9125 (9910-P64) UPS Installation Guide for IBM
C A U T I O N
® S
Applications 164201637 Rev A
INSTALLATION
UPS
UPS Battery
Connector
EBM Cable
EBM
EBM Battery
Connectors
EBM
15
