RANDOM Button 4Q

This instructs the CD player to play tracks from the entire disc in random
order. Once all of the selections have been played once, the disc will stop
playing, unless the REPEAT Button (see below) has been engaged, in which
case the random play will continue until the STOP button is pressed. When
the RANDOM button is engaged, the

REPEAT Button 9B

This button allows you to repeat the current track or the entire disc continuously
until the feature is cancelled by disengaging the REPEAT button or pressing
STOP. The REPEAT button steps sequentially through the available options.
Press the button once and the RCD-1570 will repeat just the current track.
The icon appears in the Display. Press the button a second time and
the RCD-1570 will repeat the entire disc. A second
Display. Press the button a third time to cancel the REPEAT function.
As noted above, REPEAT can be used in conjunction with the RANDOM
play feature.
NOTE: The RANDOM, REPEAT and SCAN may not work when playing
MP3 and WMA discs.

SCAN Button 0C

This feature automatically plays the first ten seconds of each track on the
disc (or the memorized program). To activate the feature, press the SCAN
button. The icon appears in the Display. To stop scanning and resume
normal operation at the current track, press the SCAN button again or press
q F
the PLAY button.
NOTE: The RANDOM, REPEAT and SCAN may not work when
playing MP3 and WMA discs.

TIME Button -H

Normally, the RCD-1570 displays the elapsed time of the currently playing
track. The TIME button allows you to see alternative time displays. Pressing
the button once displays the time remaining in the current track, which
counts down as the track continues playing. Pressing the button a second
time displays the time remaining on the entire disc (or memorized program).
When the alternative time displays are selected an " " icon appears in
the display. Pressing the button a third time reverts to the standard elapsed
time display.
NOTE: When playing MP3 and WMA discs, only the regular elapsed
time and the time remaining in the current track can be displayed.

Computer I/O Connector i

The RCD-1570 can be controlled via RS232 for integration with automation
systems. The COMPUTER I/O input accepts a standard straight DB-9 Male-
to-Female cable.
For additional information on the connections, software, and operating codes
for computer control of the RCD-1570, contact your authorized Rotel dealer.
icon appears in the Display.
icon appears in the
Rotel Link o
This 3.5 mm stereo mini-jack (labeled ROTEL LINK IN) can optionally attach
to Rotel network enabled products with ROTEL LINK OUT connections. This
allows the attached Rotel products to communicate with each other and
be controlled via the Rotel Remote App (available for download on the
iTunes ® store).

EXT REMOTE IN Jack p

This 3.5mm mini-jack receives command codes from industry-standard infrared
receivers via hard-wired connections. This feature could prove useful when
the unit is installed in a cabinet and the front-panel sensor is blocked. Consult
your authorized Rotel dealer for information on these external repeaters and
the proper wiring of a jack to fit the mini-jack receptacle.

Remote Control Advanced Buttons

SETUP Button P

Remote Only
By pressing the SETUP button, you can enter the following setup menu.
• DIMMER: Changes the display brightness.
NOTE: This setting is saved permanently including after powering off the
RCD‑1570.
• VERSION: Shows the current software version.
• EXIT: Exits this SETUP menu.
From the remote control, press the STOP/PAUSE/TRACK keys to change the
contents of the menu, press PLAY to enter the setting or confirm.
NOTE: You can also access the SETUP menu without the remote control.
Press the STOP key on the front panel for 5 seconds. Press the TRACK
buttons to change the contents of the menu and press STOP to enter
the settings or confirm.

DIM Button L

Remote Only
L
Press the DIM key sequentially to change the DISPLAY brightness.
NOTE: Adjustments made using the
saved after powering off the RCD‑1570.
L
button is temporary only and not
