ATTIX 110

Filter disassembly and replacement

DANGER !
Filter replacement is a serious matter.
The filter must be replaced with one of identical
filtering surface characteristics.
Otherwise, the vacuum cleaner will not operate
correctly.

Filter replacement

See fig. 10.
Before proceeding with these operations, turn off the
vacuum cleaner and remove the plug from the power
socket.
- Release stop "A", unscrew filter shaker knob "B"
and remove head "D".
- Release the two closing hooks "C", lift the filter "E"
and unscrew the clamp "F" that holds the filter on
the bearing ring "G".
- Unscrew cage "H" and overturn the filter, exposing
coupling clamp "I".
- Release the clamps and detach the cage from the
filter.
- Dispose of the filter according to the laws in force.
- Fit the new filter and secure it in the cage with
special clamps. Assemble the components in the
reverse order of disassembly.

Motor cooling fan inspection and cleaning

Periodically clean the motor cooling fan to prevent
the motor from overheating, especially if the vacuum
cleaner is used in a dusty place.
GB

Tightness inspection

Hoses check (fig.11)
Check that the hose "A" is in good condition and
correctly fixed.
If the hose is damaged, broken or badly connected to
the unions, it must be replaced.
When sticky materials are treated, check for possible
clogging along the hose, in the inlet and on the baffle
plate inside the filtering chamber.
Scrape the inlet from the outside and remove the
deposited waste as indicated in the figure.
Filtering chamber head tightness check (fig.12)
Check that head "A" makes a seal with filtering
chamber "C". If the gasket "D" has become slack,
unscrew the screws "B".
Lower the clips until there is a perfect seal between
the head and suction chamber, then tighten the screws
"B".
Filtering chamber/dust container tightness check
(fig.13)
If the gasket "A" between the container and the filtering
chamber "C" fails to guarantee tightness:
- loosen the four screws "B" that lock the filtering
chamber "C" against the vacuum cleaner
structure;
- allow the filtering chamber "C" to lower down and
tighten the screws "B" once it has reached the
tightness position.
The gasket must be replaced if it is torn, cut, etc...
Replace the gasket "A" if the degree of tightness is still
not optimum.
