Lift position key (4&6) (Fig. 23a and Fig. 23b)
6
4 Fig.23a
Fig.23b
Assembling the stand pillar RV 8.1 (Accessories)
No stand is required if the condenser has been properly fitted
and secured by tightening the condenser union nut on the rotary
drive.
The purpose of the stand is solely to prevent the condenser
twisting.
WARNING
Caution: If the RV 8.1 stand is fitted incorrectly, the strong forces
at the Velcro strap can cause stresses within the glass, which in
turn can cause damage to the glass condenser.
After the condenser has been fitted, the RV 8.1 stand is attached
to the rotary drive. Make sure that the condenser is installed
parallel to the lift body.
- Guide the stand rod through the hole on the underside of the
rotary drive,
- Screw the knurled screw into the tapped hole but do not tighten
it,
- Move the stand until the upper rubber sleeve rests against the
glass condenser,
- Tighten the knurled screw finger-tight,
- Secure the condenser to the stand using the pre-fitted Velcro
strap.
30
To adjust the lift position, grasp the handle and press the left or
right lock button (4).
The hand must rest on the sensor (6).
Note: Hand detection sensor (6), only to be touched by hand,
do not press!
The lift lock is unlocked and you can move the lift up and down.
Release the lock button or remove the hand from the lift, the lift
is locked in the adjusted position.
When locking and unlocking, a clear "click" sound is heard.
Stand pillar RV 8.1
Condenser Rotary drive
Fig.24

Maintenance and cleaning

The device is maintenance-free. It is only subject to the natural
wear and tear of components and their statistical failure rate.
Cleaning
For cleaning disconnect the mains plug!
Use only cleaning agents which have been approved by IKA to
clean IKA devices.
These are water (with tenside) and isopropanol.
Wear protective gloves during cleaning the devices.
Electrical devices may not be placed in the cleansing agent for the
purpose of cleaning.
Do not allow moisture to get into the device when cleaning.
Before using another than the recommended method for clean-
ing or decontamination, the user must ascertain with IKA that this
method does not destroy the device.

Accessories

For accessories see www.ika.com.

Error Codes

Any malfunctions during operation will be identified by an error message on the display.
Once a serious error message has been displayed, the lift moves to the top end position and the device can no longer be operated.
Proceed as follows in such cases:
- switch off device using the main switch,
- carry out corrective measures,
- restart device.
Error code Cause Effect
E03 Temperature inside the device Room temperature > 40 °C
is too high
E04 Target speed is not reached Load too large
Motor blocked Cable break
E09 Flash memory storage error Transmission error
If the actions described fail to resolve the fault or another error code is displayed, then take one of the following steps:
- contact the service department,
- send the device for repair, including a short description of the fault.
Spare parts order
When ordering spare parts, please give:
- device type.
- serial number, see type plate.
- position number and description of spare part,
see www.ika.com.
- software version.
Repair
Please only send devices in for repair that have been
cleaned and are free of materials which might present
health hazards.
For repair, please request the "Safety Declaration (Decontami-
nation Certificate)" from IKA or use the download printout of it
from IKA website at www.ika.com.
If your appliance requires repair, return it in its original packaging.
Storage packaging is not sufficient when sending the device - also
use appropriate transport packaging.
Correction
- Switch off the device
- Let the device cool down
- Check the location (see Technical data)
- Reduce the volume in the evaporator
- Turn the unit off and on again
