User manual

5. - HOW TO USE THE PRODUCT

To carry out the configuration of each SAT-
RF module, it is necessary to use the pro-
grammer and follow these steps:

5.1.- Normal menu

Insert the programmer in the front connector
of the module (" Program."). First, the ver-
sion of the software in use, will appear. For
example 1.13:
a.- Output channel
After a couple of seconds, the first menu
appears, which is the output channel, for
example 174.25 MHz:
To change the value indicated, you must
press the , button, this will make the
selected digit flash on and off. By using the
and buttons, you can change the value
of the digit. By pressing the
the following digit is selected, which can be
changed in the same way. When the cursor
is placed on top of the decimal digit/s and
when you press the
following permitted values will appear:
• .0 => .00 MHz
• .2 => .25 MHz
• .5 => .50 MHz
• .7 => .75 MHz
The range of input values is from 46 to 862
MHz.
The selection of the output channel is pos-
sible if the channel mode has been chosen
(see extended menus). In this case, the
number of the chosen channel will appear,
for example, channel 5:
b.- Output level
By pressing the
gain access to the output level selection. In
this case, the cursor is not used for the
selection of the digit, and instead the
buttons are used to choose the output
level between 00 (minimum) and 99 (maxi-
button again,
mum). For example, 85:
and buttons, the
c.- Input frequency
The following menu allows the user to enter
the input frequency. This is done in the
same way as the output frequency menu;
the
that you wish to modify, and you can either
increase or decrease its value using the
or
input frequency values is from 950 to 2150
MHz. For example, for 1334 MHz:
d.-Demodulated subcarrier
By pressing the
the following display which lets you enter
the demodulated audio subcarrier fre-
quency. As is the case for the output fre-
button, it is possible to
quency menu, the
the digit that you want to modify, and you
can either increase or decrease its value
and
using the
range is from 5.00MHz to 8.50MHz:
28
SAT-RF
button allows you to select the digit
. buttons. The range allowed for the
button, you can access
button lets you select
and buttons. The permitted
