Technical Data
Control
Valve option pressure
[bar]
5/2 SR 2.5–10
5/2 2.5–10
5/3 2.5–10
2x3/2 NC 2.5–10
5/2 AR 2.5–10
2x3/2 NC/NO 2.5–10
2x3/2 NO/NC 2.5–10
2x3/2 NO 2.5–10
1)
Required control pressure curve 2x3/2-way directional control valves, with externally supplied pilots and the main
supply through port 1. See diagram below:
pc = control pressure in bar
pw = working pressure in bar
Working
pressure,
internal pilot
control [bar]
2.5–10
2.5–10
2.5–10
1)
2.5–10
2.5–10
1)
2.5–10
1)
2.5–10
1)
2.5–10
Working
Switching
pressure,
time
external pilot
t /t
F E
control [bar]
-1–10 16/29
13/40
-1–10 12/14
13/15
-1–10 14/15
14/15
-1–10 17/28
20/33
-1–10 17/26
19/30
-1–10 17/28
20/33
-1–10 17/28
-1–10 17/28
20/33
Flow rate [Nl/min]
Supply
[ms]
port 1 ports 3–5
825
970–1100
825
970–1100
750
950–1100
850
970–1100
825
970–1100
850
970–1100
850
– –
850
970–1100
Supply
800
800
750
750
800
750
750
750
