15. TECHNICAL DESCRIPTION
15.1 SPECIFICATIONS
Inogen Rove 6 Portable Oxygen Concentrator (Model # IO-501)
Mains Isolation
Dimensions with standard battery
Dimensions with extended battery
Weight with standard battery
Weight with extended battery
Nominal sound level
Warm up time
Oxygen concentration*
Inspiratory trigger pressure sensitivity
Flow control settings
Maximum outlet pressure
AC Power
DC Power
Battery type
Rechargeable battery:
Battery re-charge time
Operating temperature**
Operating humidity
Operating atmospheric pressure
Operating altitude**
Shipping and storage temperature
Shipping and storage humidity
Measurement uncertainties:
*Based on atmospheric pressure of 101.3 kPa (14.69 psi) at 20˚ C (68˚ F) & Dry (STPD).
**Operating outside of these operational specifications can limit the concentrator's ability to meeting Oxygen
Concentration specification at higher liter flow settings.
©2022 Inogen, Inc. All rights reserved.
Remove both the DC input cord from device as well as the battery pack.
7.2 x 3.3 x 8.2 in (18.3 x 8.3 x 20.5 cm)
7.2 x 3.3 x 9 in (18.3 x 8.3 x 22.9 cm)
4.8 pounds (2.2kg)
5.8 pounds (2.6kg)
39 dBA typical at setting 2 (MDS-Hi)
Maximum system sound power of 62 dBA
Maximum system sound pressure of 54 dBA
Typical lowest alarm sound pressure of 62.3 dBA (Measured in the carry bag)
Typical highest alarm sound pressure of 67.5 dBA (Measured in the carry bag)
(Sound pressures measured at 1 meter per ISO 3744
2 minutes
90% + 6% and - 3% at all settings
<0.12 cm H20
Pulse dose setting 1,2,3,4,5,6
< 22 PSI
18.7 PSI (129 kPa) ± 10%
100 to 240 VAC, 50 to 60 Hz
Autosensing 2.0 – 1.0A
13.5-15.0VDC,100W
Max voltage: 12.0 to 16.8 VDC (+ 0.5)
Lithium ion
12.0 to 16.8 VDC (± 0.5V)
Standard (BA-500 & BA-508): up to 3 hours
Extended (BA-516): up to 4 hours
41 to 104˚F (5 to 40˚C)
15% to 90%, non-condensing
70 kPA to 106 kPA
0 to 10,000 ft (0 to 3048 meters)
-13 to 158˚F (-25 to 70˚C)
Up to 90%, non-condensing
Store in a dry environment.
Pulse volumes: ± 15% of rated volume
Pressure: ± 0.03 psig (General) / ± 0.05 cm H2O (Inspiratory Trigger Sensitivity)
Oxygen concentration: ± 3% (not accounting for temperature, barometric
pressure, and time from measurement device calibration)
