Parkside Performance PABSP 20 Li C3 Instructions D'utilisation Et Consignes De Sécurité page 47

Hard screw joints (in metal)
Particularly high torque occurs, for example in
o
metal screw joints made using drive sockets.
Select a low rotational speed.
Soft screw joints (e.g. in soft wood)
Again, use a low rotational speed, e.g. to
o
avoid damaging the surface of the wood
upon contact with the screw head. Use a
countersink.
Drilling in wood, metal and other
materials
Use a high speed for drill bits with small
o
diameter and a low speed for drill bits with
large diameter.
Select a low speed for hard materials and a
o
high speed for soft materials.
Secure or fasten the workpiece in a clamp or
o
vice (if possible).
Mark the spot where you want to drill using a
o
centre punch or nail. Select a low rotational
speed when starting.
Pull the rotating drill bit from the hole
o
repeatedly to remove dust and chips and
clear the hole.
Drilling in metal
Use a metal drill (HSS). For optimum results,
o
cool the drill bit with cooling lubricant (cutting
oil). Metal drill bits can also be used to drill
into plastics. Start with a 3 mm diameter drill
bit and then increase the size until the desired
hole diameter is achieved.
Drilling in wood
Use a wood drill with a lathe centre.
o
Deep holes: Use an auger bit.
Large-diameter holes: Use a Forstner bit.
Small screws can be screwed directly into soft
wood.
Belt clip (fig. J)
m CAUTION! RISK OF INJURY!
Before hanging the product in the belt:
u
Push the rotation direction switch
the centre position (lock). This prevents
the product from being switched on
accidentally.
The belt clip allows the power tool to be
[ 9 ]
o
hooked on belt or pocket.
˜ Activate/deactivate the
Bluetooth function on the
battery pack
NOTE
The Bluetooth function is only available for
u
Parkside smart batteries PAPS 204 A1 and
PAPS 208 A1. The included battery pack
PAP 20 B1 does not feature the Bluetooth
function.
Press and hold the
o
pack for 3 seconds to activate the Bluetooth
function. The yellow charging level LED lights
up. The Bluetooth function is enabled.
Release the button.
o
Press and hold the
o
battery pack for 10 seconds to deactivate
the Bluetooth function. The yellow charging
level LED goes off. The Bluetooth function
is deactivated. In the Lidl Home app the
battery pack is shown as offline.
˜ Connecting the product to the
Lidl Home App
NOTE
The product can only be connected to the
u
Lidl Home app if the battery pack is
inserted in the product.
Only Smart Performance rechargeable
u
batteries can be connected to the Lidl
Home app.
to
5 ] [
button on the battery
button on the
GB/IE 45
