The Lidl Home app can be used
with this product.
˜ Scope of delivery
m WARNING!
The product and the packaging are not
u
children's toys! Children must not play with
plastic bags, sheets and small parts! There
is a danger of choking and suff ocation!
1 Cordless drill 20 V PABSP 20 Li C3
1 Battery pack PAP 20 B1
1 Battery charger PLG 20 C1
1 Carrying case
1 Instruction manual
˜ You will need (for use with
the Lidl Home app)
Mobile device:
iOS 9.0 or higher
Android 5.0 or higher
˜ Parts description
Figure A:
Chuck
1 ] [
Chuck ring
2 ] [
Torque sleeve
[ 3 ]
Gear selector
4 ] [
Rotation direction switch/lock
[ 5 ]
On/off switch/speed control
[ 6 ]
Grip handle
7 ] [
Bit holder (magnetic)
[ 8 ]
Belt clip
9 ] [
Battery pack
[ ]
34 GB/IE
LED work light
[ ]
Connection status LED
[ ]
Figure B:
Battery pack
[ ]
Release button for battery pack
[ ]
button (charging level)
[ ]
Charging level LEDs (red/orange/green)
[ ]
Figure C:
Battery pack
[ ]
Battery charger
[ ]
Mains cord with mains plug
[ ]
Charging control LED – Green
[ ]
Charging control LED – Red
[ ]
Not illustrated:
Carrying case
[ ]
˜ Technical data
Cordless drill
Rated voltage:
Drill chuck type:
Gearbox:
No-load speed n :
0
1 gear:
st
2 gear:
nd
Max. torque:
Chuck clamping range:
Max. drill diameter:
Battery pack
Type:
Rated voltage:
Capacity:
Energy value:
Number of cells:
PABSP 20 Li C3
20 V
keyless chuck
2 speed
0 – 500 min
–1
0 – 2000 min
–1
60 N m
max. Ø 13 mm
into steel Ø 13 mm
into wood Ø 38 mm
PAP 20 B1
Lithium-Ion
20 V max.
2 Ah
40 Wh
5
