EN
ERROR
CODES
Diagnosis and servicing must only be carried out by qualifi ed personnel.
Sound plus fl ashing red LED: board in alarm.
Red LED only fl ashing, normal operation. The number of fl ashes indicates the last stored error.
Buzzer sound
alarm/ LED ALARM TYPE
fl ashes
5 OVERTEMPERATURES
6 CALIBRATION FAIL
7 OVERCURRENT
8 POWER FUSE/RELAY
9
UNDERVOLTAGE
10 OVERVOLTAGE
11
OVERLOAD CURRENT
12 ENCODER FAILURE
13 KEY OFF
14 EEPROM FAIL
NOTE: if alarm 11 trips during closing (an obstacle has been detected), the door reopens
automatically and closes after the set time;
on the third consecutive attempt at closing (which occurs at reduced speed) with tripping of alarm
11, the door stops defi nitively during opening. To reset the alarm, the door must be started manually
or a closing impulse must be given with the button (if present).
MISCELLANEOUS ERRORS and FAQ
1
During programming, the door fi rst closes and then opens.
Check the colour of the cables, (par. 6, par. 27)
Check the position of the belt jointing bracket, which must be on the side
opposite to the fastening rod (par. 23)
2
I cannot perform programming. The door stops before the cycle is completed.
(alarm 11)
- the door is too heavy: try a di erent board preset.
- there are frictions/obstacles: remove them
- there are locking brakes that engage: remove them.
- the belt is too tight
- the belt is not aligned: check the height of the belt jointing bracket with respect to the motor
pulley and the driven pulley.
3
rogramming is successful, but the door stops in reclosing and moves back.
- belt too tight: reduce tension
- mechanical friction: remove.
PROCEDURE
Temperature > 85°C: the alarm is automatically reset when the temperature drops
below 70°C.
Incorrect calibration procedure.
Turn o the board and check the motor output for shorts.
The board is damaged, replace it.
Supply voltage below 19V: check the supply voltage.
Supply voltage higher than 40V: check the supply voltage.
Working current too high.
Check for any obstacles in the door path.
The alarm resets itself after 2 seconds.
Encoder signal missing during movement. Check the connections.
The alarm resets itself after 0.5".
Supply voltage lower than 18V. Turn o the board.
Stored data have been lost/damaged.
Turn o the board and perform the path acquisition procedure again.
