Insert the block into the rail profi le.
2
Note: The sign indicates the bottom side!
4
Insert the motor unit
Make sure the 2 motor power wires are positioned
6
with the correct polarity.
-0V
8
Push the motor unit all the way into the rail, holding
back the belt. See next step for correct position.
R1387 DCM2461/SCRIGNO | page 6
+24V
Guide the rear block inside the rail by a few
3
centimetres
Once the slot has been found, insert and tighten
5
the screw of the previously-removed block.
7 Position the belt around the pulley
9
Correct mounting position:
1: the motor is on the bottom of the rail
2: the belt is ON THE OUTSIDE of the motor cable
