2. CONTENTS OF THE PACKAGE

A
D
3. INSTALLATION
1. STATUS
2. POWER
3. (INPUT)
4. (EMITTERS 1 till 4) Connection for max. 4 IR Extension cables with each 2 IR LEDs.
5. Fastening holes
4
B
E
1
2
V+
G
3
ST
IR
Connection for a STATUS power adapter (not supplied)
Connection for the POWER power adapter (supplied)
Connection for max. 3 IR receiver(s) (1 x supplied)
(2 x supplied)
for stable assembling of the IR Module on a smooth underground.
C
A. 1 x IR Module
B. 1 x IR Receiver
C. 2 x IR Extension cable
with 2 IR LEDs
D. 1 x Power adaptor
E. 1 x Manual
1
2
4
3
4
5
Picture 1
