CHOKE CONTROL SYSTEM
ENGINE DOES NOT START, ENGINE STARTS BUT STALLS, ENGINE SPEED
DOES NOT INCREASE, OR ENGINE SPEED IS UNEVEN.
Check AC output.
GOOD
Rotate the shaft of the choke control motor to check if
it turns smoothly with slight resistance.
GOOD
Measure the coil resistance between 3-1, 3-2, 3-4,
and 3-5 of the auto choke motor.
(Tester range: Ω × 100)
Coil resistance:
250 Ω ± 7% at 25 °C (77 °F)
GOOD
*
CHOKE CONTROL SYSTEM
NOT GOOD
NOT GOOD
OUT OF SPECIFICATION
Refer to "GENERATOR SYSTEM" (page
17).
Replace the choke control motor.
Replace the auto choke motor.
22
TRBL
