CONTROLS,
INDICATORS AND CONNECTORS
C [POWER] POWER switch
Turn the power ON and OFF with this switch.
D Battery holder
Mount the optional battery pack BN-V428 here.
( See page 34.)
E Battery lock release button
Press this button to remove the battery pack.
F [DC INPUT] DC connector
Power input connector for 7 V DC. Accepts the
optional AC adapter AA-P30. The power range
is 6 V to 12 V.
G REC Start/Stop button
This button starts and stops recording. When
the GY-DV300 is in the shooting mode, pressing
this button starts the recording. Pressing the
button during a recording engages the
recording-pause (standby) mode.
H [MODE] Mode selector switch
Set in accordance with the operating mode of
the GY-DV300. When used in the shooting mode,
the switch is set to "CAM-A" or "CAM-B". When
used in the VTR playback mode, it is set to
E-14
!8
@0
!9
MODE
CAM-B
CAM-A
GAIN
BAR
MENU
AW
FWD
AUDIO
CH-1
MIC1
MIC2
REV
MONITOR
CH-1
MIX
@1 @2 @3 @4

Rear Section

POWER
OFF ON
PUSH
VTR
SHUTTER
CH-2
CH-2
"VTR". When set to "CAM-A" or "CAM-B" in the
shooting mode, two separate sets of setting
values for recording can be set by means of the
menu screens.
"CAM-A" : In this position, shooting takes
"CAM-B" : In this position, shooting takes
: ● Set to this position when
"VTR"
I [GAIN] Sensitivity selector button
This button is for manual adjustment of
sensitivity. It works when the AE item is set to
OFF on the OPERATION menu screen.
!3
!5
!7
!4
!6
place in accordance with the
conditions set for "CAM-A" on the
menu screen.
place in accordance with the
conditions set for "CAM-B" on the
menu screen.
performing VTR playback.
Also set to this position to record
the video signal output from the
DV connector with another video
component equipped with DVI/
O connector.
● Set to this position to record the
video signal input from the DV
connector. (GY-DV301only)
