2. Bring the handle bar to vertical position
B (Fig. 5).
3. Remove the child car seat as illustrated
above by pressing button P.

2.2 INSTALLATION WITHOUT BASE

To install the child car seat without the base,
proceed as follows:
1. Position the child car seat on the selected
car seat (Fig. 15) rear facing.
2. Pull the vehicle safety belt and fasten it
to the relevant buckle, inserting the hori-
zontal (waist) part of the belt through the
child car seat's two blue slots (K) (Fig. 15).
3. Take the diagonal car safety belt and
thread it through the relevant blue slot (O)
on the back of the child car seat's backrest
(Fig. 16) WARNING! When travelling by car,
this diagonal safety belt must ALWAYS be
threaded through this slot.
4. Pull the belt as tightly as possible, without
leaving any slack and making sure it is
not twisted.
5. Turn the carry handle to position A (Fig. 17).
To remove the child car seat:
1. Release the car safety belt by pressing
the buckle.
2. Bring the carry handle into the position
B (vertical).
3. Unthread the belt through the diagonal
and horizontal slots.

3. OTHER OPERATIONS

3.1 PLACING THE CHILD IN THE CHILD
CAR SEAT AND ADJUSTING THE
SAFETY HARNESS
To adjust the harness straps, proceed as follows:
1. Pressing the adjustment button (Fig. 2 - I)
and pull the child car seat harness straps
to loosen them (Fig. 18).
2. Press the red button (Fig. 19A) to open
the buckle and keep the harness straps
spread apart (Fig. 19B).
3. Place the baby on the seat. WARNING! The
harness straps must always be adjusted
to adapt to the child's growth phase. Be-
fore installing the child car seat inside the
vehicle, adjust the harness straps to the
right height. To adjust them correctly, the
harness straps must come out from the
backrest at the height of the child's shoul-
ders (Fig. 20). The headrest and straps can
be adjusted simultaneously in height to
6 different positions using button Q (Fig.
4-A) to follow your child's growth.
4. Overlap the two ends of the harness
straps, insert them together inside the
buckle until you hear them clicking (Fig.
21) WARNING! Never insert just one end
of the harness into the buckle and do not
insert them one at a time. Press button Q
to adjust the straps.
5. Tighten the child car seat's safety harness
by pulling the adjustment strap (Fig. 22).
WARNING! The booster cushion guarantees
the correct support and the ideal position
for the neck and back of babies from when
they are born until they weigh about 6 kg.

3.2 USE AS BABY BOUNCING CHAIR

When the child car seat is not used in a car,
it can be used as a baby bouncing chair.
Place the child car seat only on stable hori-
zontal surfaces.
WARNING! Before carrying the child car seat,
always move the carry handle to position
B (vertical).
WARNING! Never leave your child unat-
tended.
WARNING! Always use the restraint system.
WARNING! Using the child car seat on raised
surfaces such as tables, chairs etc. can be
very dangerous.
WARNING! This child car seat is not designed
for long periods of sleep.
WARNING! Do not use the seat when the
child is able to sit up independently.
This child car seat is not a replacement for a
bed or cot. If children needs to sleep, they
should be moved to a bed or a cot.
Do not use the child seat if any of its parts
are broken or missing.

3.3 USE WITH THE STROLLER

The Oasys 0+ UP car chair seat can be used
with the LOVE, LOVEmotion, LOVE UP – Style-
Go, StyleGo UP.
WARNING! Please read the Stroller instruc-
tion manual when using the child car seat
on the stroller.
Before fastening the child car seat, remove
the stroller seat.
To install the child car seat on the stroller,
19
