Operation
4.2
Controls and Service Locations
Ref. Description
1
Handle locking pin
2
Tie-down location
3
Scraper bar (4 total)
4
Water control valve
5
Shock mount (4 total)
6
Parking brake
7
Back-up stop pad
8
Forward/reverse control lever
9
Exciter control lever
10
Water tank fill cap
11
Crank storage location
12
Throttle control
13
Air cleaner indicator
14
Oil dipstick
All manuals and user guides at all-guides.com
Ref.
15
16
17
18
19
20
21
22
23
24
25
26
27
28
24
Description
Crank guide sleeve
Fuel tank fill cap
Top cover
Hydraulic tank (under front cover)
Hydraulic tank fill port (under top cover)
Hydraulic tank sightglass (through slots)
Fuel tank
Front cover
Lifting eye
Operator's Manual holder
Water tank
Battery
Ignition switch
Alarm
RD 7
