7.4 Configuration

Before powering the device it must be configured
correctly by setting the dip-switches inside the
configuration window. Open the window by undoing
the screws as shown in the illustration:
Fig. 36

7.4.1 Dip-switch configuration

The following diagram represents the position of
the dip-switches when the configuration window is
opened.
j When the dip-switch rocker is up it
represents the value 1 (ON) while if it is
down it represents the value 0 (OFF). This
rule is valid for all dip-switches except for
in the section "7.4.6 Serial terminations/
connections", page 23 where they are
inverted.
Rocker up = ON = 1
Rocker down = OFF = 0
Rocker up = OFF = 0
Rocker down = ON = 1
Fig. 37
Baudrate Protocol Serial and Address
Termination of
RS485 lines
Fig. 38
RS232 serial
connector

7.4.2 Setting the baud rate

Dip-switches 4, 3 and 2 are used to set the
communication rate of the device according to the
table below.
Dip-switch number 1 is used to update the firmware.
During normal use, make sure the rocker is OFF
(DIP1=OFF).
j When the dip-switch rocker is up it
represents the value 1 (ON) while if it is
down it represents the value 0 (OFF).
BAUDRATE SETTING
Description DIP
4
Baudrate OFF OFF OFF
adjustment
ON OFF OFF
OFF ON OFF
ON
OFF OFF ON
ON OFF ON
OFF ON
ON
Firmware update -
-
Tab. 08

7.4.3 Setting the protocol

Video positioning systems with the ULISSE line can be
controlled by a range of protocols.
j When the dip-switch rocker is up it
represents the value 1 (ON) while if it is
down it represents the value 0 (OFF).
PROTOCOL SETTING
DIP DIP
8 7
MACRO OFF OFF OFF OFF OFF ON
(VIDEOTEC)
PANASONIC OFF OFF OFF ON OFF ON
PELCO D OFF OFF OFF OFF ON
AMERICAN OFF OFF OFF OFF ON
DYNAMICS
VISTA OFF OFF OFF ON
Tab. 09
DIP DIP DIP Configuration
3 2 1
- 300 baud
- 600 baud
- 1200 baud
ON OFF - 2400 baud
- 4800 baud
- 9600 baud
ON - 19200 baud
ON ON - 38400 baud
- - ON Set up enabled
- - OFF Set up disabled
DIP DIP DIP DIP DIP
6 5 4 3
ON
OFF OFF
OFF OFF ON
ON ON
OFF OFF ON
DIP
2 1
ON
OFF
ON
21
