INSTALLATION AND OPERATION MANUAL
555CFK Circulating Fan Kit
Use with Valor Portrait 530, Retrofi re RF24DV and Madrona MF28
WARNING
If the information in these instructions is
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
GROUNDING: This power supply must
be installed and grounded in accordance
with local codes, or in the absence of local
codes, with the current Canadian Electrical
Code CSA C22.1. or in the USA the National
Electrical Code ANSI/NFPA70 latest edition.
Description of System
The models listed above have been designed to
accommodate the installation of an air circulation fan.
Operated by a variable speed control and a thermally
actuated switch, the fan is designed to boost the natural
convection through the heater; this may be a desirable
feature dependent on the fireplace location and room
layout.
The circulating fan may be installed before the heater
installation or as a retrofit at a later date.
Operation
The fan is designed for automatic operation using a
thermal switch. It will take approximately 10-15 minutes
for the appliance to warm up and allow the switch to
activate the fan.
To operate the fan, rotate the speed control knob
clockwise from OFF to HIGH. Further rotation will control
the fan speed, once the automatic thermal switch has
been activated.
4000510-10
© 2021, Miles Industries Ltd.
555CFK
This kit must be installed or serviced by
a qualified installer, service agency or
the gas supplier. These instructions are
to be used in conjunction with the main
installation instructions for the above
listed models.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
If the fire is turned off, the fan will continue to operate
until the thermal switch cools, unless the speed control
is manually turned to the OFF position.
Should electrical power fail, the heater operation will
remain unaffected.
Electrical Requirements
The fan kit requires a power supply of 120 Volts,
1 phase, 60 Hz. Full load current is less than 1 amp.
1
