Maintenance and cleaning

The IKAMAG RO 5 power, RO 10 power or RO 15 power and IKA-
MAG RT 5 power, RT 10 power or RT 15 power are maintenance-
free. It is subject only to the natural wear and tear of components
and their statistical failure rate.
When ordering spare parts, please give the manufacturing
number shown on the type plate, the machine type and the
name of the spare part.
Please send in equipment for repair only after it has been cleaned
and is free from any materials which may constitute a health hazard.
Use only cleansing agents which have been approved by IKA to
clean IKA devices. To remove use:
Dyes
Construction materials water containing tenside / isopropyl alcohol
Cosmetics
Foodstuffs
Fuels
For materials which are not listed, please request information from
IKA. Wear the proper protective gloves during cleaning of the devi-
ces. Electrical devices may not be placed in the cleansing agent
for the purpose of cleaning.

Associated standards and regulations

Construction in accordance with the foolwing safety standards
EN 61 010-1
Construction in accordance with the foolwing EMC standards
EN 50 082-1
Associated EU guidlines
EMC-guidlines: 89/336/EWG
Machine guidelines: 73/023/EWG
RO/RT 0205
isopropyl alcohol
water containing tenside / isopropyl alcohol
water containing tenside
water containing tenside
UL 3101-1
CAN/CSA C22.2 (1010-1)
EN 55 014 EN
60 555-2; -3

Accessories

IKAFLON stirrers, PTFE, 8 mm dia length 30mm
RSE
Stirrer remover
Recommended IKA accessories
EH 4 basic suspension thermostat
RO 5.1
bath vessel
RO 10.1
bath vessel
RO 15.1
bath vessel

Technical data

Design voltage:
VAC 230±
or
VAC 115±
Design frequency:
Hz
Motor:
Speed range:
rpm 0 to 1100
Deviation between the -
%
stirrer points
Perm. ambient temperature:
°C
Perm. relative humidity:
%
Perm. ON duration:
%
Interference suppression:
Protection to DIN 40 050:
Mounting surface
mm 120 x 440
mm 180 x 440
mm 270 x 440
RT: Max surface
°C
temperature
RT: Temperature constancy
K
in the medium
10%
10%
50/60
ball-bearing brushless
EC motor
infinitely variable
5
+5 to +40
80
100
to VDE 0871
IP 42
(RO 5)
(RO 10)
(RO 15)
120
± 2 depending on the container
9
